Fluoropolymer lined piping systems provide proven chemical resistance, thermal stability, and long-term corrosion protection for critical chemical processing applications. Our range includes PTFE, PFA, PVDF, PP, HDPE, and ETFE lined pipe and fittings.
Enquire Now
Our Fluoropolymer lined piping systems combine robust steel exteriors with advanced polymer linings — including PTFE, PFA, PVDF, PP, HDPE, and ETFE — to safely handle aggressive acids, alkalis, and solvents across a wide range of temperatures and pressures.
Our lined piping systems are ASTM F1545-15A type tested and engineered to handle highly corrosive mediums across a broad range of flow, pressure and temperature requirements.
| PTFEPolytetrafluoroethylene | PFAPerfluoroalkoxy Alkane | PVDFPolyvinylidene Fluoride | PPPolypropylene | HDPEHigh-Density Polyethylene | ETFEEthylene Tetrafluoroethylene | |
|---|---|---|---|---|---|---|
| Size Range | 25NB – 600NB | 25NB – 300NB | 25NB – 300NB | 25NB – 300NB | 25NB – 600NB | 25NB – 300NB |
| Pressure Class | CLASS 150 / 300 | CLASS 150 / 300 | CLASS 150 / 300 | CLASS 150 / 300 | CLASS 150 | CLASS 150 / 300 |
| Temperature | Up to +200°C | Up to +200°C | Up to +135°C | -60°C to +100°C | -50°C to +80°C | Up to +150°C |
| Chemical Resistance | ||||||
| Abrasion Resistance | ||||||
| Description | Outstanding chemical resistance across virtually the entire pH range. Ideal for handling aggressive acids, alkalis, and solvents. | Similar properties to PTFE with improved flow characteristics and weldability. Excellent for high-purity applications. | Excellent mechanical strength combined with chemical resistance. Suitable for high-purity and abrasive chemical slurries. | Cost-effective corrosion protection for a wide range of acids, bases, and organic solvents at moderate temperatures. | Excellent abrasion and impact resistance. Ideal for slurry transport, mining, and water treatment applications. | High mechanical strength with excellent chemical resistance. Superior abrasion resistance compared to PTFE and PFA. |
Speak to our team about fluoropolymer lined systems. for your next project.
